125KVA Weichai Mobile Trailer Rainproof Canopy Diesel Generator Set 100KW Backup Emergency Power Supply Self Start

Name: 125KVA Weichai Mobile Trailer Rainproof Canopy Diesel Generator Set 100KW Backup Emergency Power Supply Self Start
Brand: Weichai
Price: 11 USD

China 125KVA Weichai Mobile Trailer Rainproof Canopy Diesel Generator Set 100KW Backup Emergency Power Supply Self Start wholesale

Warranty : 3months-1year

Place of Origin : China

Brand Name : Weichai

Model Number : WP6D132E200

Rated Voltage : 230V, 400V

Rated Current : 180A

Speed : 1500RPM, 1800RPM

Frequency : 50/60HZ

Starting system : Auto Start

Type : Trailer Type, Silent type, Container Type, Super Silent Type, Open Frame, Portable Type, Mobile Type, Canopy Type, Silent

Cooling System Type : Water cooling system

Alternator : Marathon

Options : Automatic Transfer Switch

Engine type : Direction Injection

Product Name : Silent speaker unit

Color : Customers' Request

Phase : 1 Phase/3 Phase

ControllerControl panel : Smargen

Rated Power : 100KW

Packaging Details : Box packaging

Supply Ability : 10 Unit/Units per Year

Price : $11,978.00/units >=1 units

MOQ : 1 unit

Contact Now

Details Images

125KVA Weichai Mobile Trailer Rainproof Canopy Diesel Generator Set 100KW Backup Emergency Power Supply Self Start

100KW Weichai Mobile Trailer Rainproof Canopy Diesel Generator Set

Weichai diesel generator set parameters 100KW 1、 Technical specifications (1) Model: 100GF Common power (KW): 100 Backup power (KW): 132 Frequency: 50Hz Output voltage: 400/230V Speed: 1500rpm Power factor: COS Φ= 0.8 (lag) Fuel consumption (g/Kw * h): 25 Maximum output current (A): 180 (recommended to use No. 0 diesel) Number of phases/lines: three-phase four wire Noise LP7m: 105dB External dimensions (mm): 2470 * 930 * 1450 (external dimensions are subject to the actual product) Weight: 1550Kg (weight based on actual product) (2) Diesel engine: Brand: Deutz Origin: Weichai Power Co., Ltd Model: WP6D132E200 Cooling start: closed water cooling Starting method: 24V DC power start Number of cylinders: 6 Diesel engine oil capacity: 18L Diesel engine coolant capacity: 16L Fuel supply method: direct injection Air intake method: turbocharging Cylinder arrangement: inline Intercooling method: water cooling Fuel model: Domestic 0 # light diesel Speed regulation method: mechanical/electronic speed regulation Oil model: WD/40 Cylinder diameter/stroke: 105/130mm (3) Generator: Brand: Marathon Stanford Origin: Jiangsu Model: ZD-100 Material: Pure copper Insulation level: H Voltage control mode: AVR Voltage: ≤ 4% Rated voltage (V): 400/230 Protection level: IP23 Frequency: 50Hz Phase number/wiring: three-phase four wire/Y-shaped winding connection Frequency adjustment rate (%): ≤ ± 0.5 (steady-state)+10~-7 (transient) Voltage adjustment rate (%): ≤ ± 0.5 (steady-state)+20~-15 (transient) Frequency fluctuation rate (%): ≤ ± 0.5 Voltage fluctuation rate (%): ≤ ± 0.5
